Ultra Series Battery Plate

The SmallHD Micro Battery Plate for Ultra Series 12V provides a compact and secure power solution for SmallHD Ultra Series monitors. Built from anodized aluminum, it delivers long-lasting durability while maintaining a lightweight profile that pairs perfectly with the Ultra 5, Ultra 7, and Ultra 10 monitors.

Compact and Durable Design

The battery plate features a small form factor that mounts directly to compatible Ultra Series monitors. Its anodized aluminum construction provides excellent durability while ensuring a secure battery connection for professional production environments.

V-Mount and Gold Mount Options

The V-Mount and Gold Mount versions support both micro and full-sized cinema batteries. Each plate includes two D-Tap outputs that supply accessory power at battery voltage from 11V to 17V, giving users additional flexibility for powering production accessories.

Integrated Accessory Protection

A resettable 5.8A digital E-Fuse protects connected accessories from excessive current draw. If the accessory load exceeds the limit, only the D-Tap outputs shut down while the monitor continues operating normally. Once the load is reduced or accessories are reconfigured, simply press the reset button to restore accessory power.

Cable-Free Installation

The battery plate mounts directly to the monitor using captive mounting screws, creating a clean installation without external power cables. This seamless integration helps maintain a compact and professional camera setup.

B-Mount Version

The B-Mount version expands battery compatibility for the Ultra 5 and Ultra 7 monitors. It attaches directly to the monitor using captive screws and an M2.5 Hex Tool, while integrated pogo pins provide a cable-free power connection. The plate accepts input voltages from 10.3V to 16.8V with a maximum current of 20A.

Key Features

• Designed for SmallHD Ultra 5, Ultra 7, and Ultra 10 monitors.
• Compact anodized aluminum construction for durability and secure battery mounting.
• Available in V-Mount, Gold Mount, and B-Mount versions.
• V-Mount and Gold Mount models support micro and full-size cinema batteries.
• Dual D-Tap outputs provide accessory power at 11V–17V battery voltage.
• Resettable 5.8A digital E-Fuse protects accessory outputs while keeping the monitor powered.
• Direct cable-free installation using captive mounting screws.
• B-Mount version accepts 10.3V–16.8V input with up to 20A maximum current.
