Close Up Diopter Set 5

The Lindsey Optics Brilliant² Tray Mount Diopter Set 5 provides five professional close-up lenses for cinema production. The set includes +1/4, +1/2, +1, +2, and +3 diopters, giving filmmakers the flexibility to achieve a wide range of close-focus effects. Each 138mm diopter is mounted in a 4″x5.65″ tray, allowing fast installation into compatible matte boxes while maintaining excellent optical performance.

Complete Diopter Set

This kit covers multiple shooting situations with five diopter strengths. The +1/4, +1/2, and +1 lenses occupy a single matte box slot, while the +2 lens uses two slots and the +3 lens uses three slots. This design makes it easy to select the right magnification for each scene.

Fast Tray Mount Design

The integrated tray mount design allows quick and simple insertion into both clip-on and rod-mounted 4″x5.65″ matte boxes. Each tray houses a large 138mm round diopter with a generous 5.1-inch clear aperture, making the set suitable for large-diameter lenses and wide-angle lenses.

Professional Optical Quality

Every lens features broadband multi-layer anti-reflection (MC) coating to reduce reflections while preserving image quality. The Brilliant² series delivers reliable optical performance for professional cinematography and close-up filmmaking applications.

Key Features

• Complete set with +1/4, +1/2, +1, +2, and +3 diopters.
• Fits selected 4″x5.65″ professional matte boxes.
• Unique tray mount design enables fast lens changes.
• Compatible with clip-on and rod-mounted matte boxes.
• 138mm round lenses with a 5.1-inch clear aperture.
• Supports large-diameter and wide-angle lenses.
• Broadband multi-layer anti-reflection (MC) coating.
• +1/4, +1/2, and +1 use one slot, +2 uses two slots, and +3 uses three slots.
