Description

Evoke 150C Eight-Color LED Light

The Evoke 150C uses the Nebula C8 Light Engine to deliver a wide color temperature range, broad color gamut coverage, excellent light quality, and precise dimming. Its compact all-in-one design makes it easy to place in tight spaces. Hide it behind props, inside vehicle cabins, or in narrow corners, then reposition it as needed. The fixture delivers 150W output and can work as a fill light for large scenes or as a key or rim light in smaller spaces.

The lamp head measures 209.14×146.95×127.29mm and weighs 2.11kg. With the yoke, it weighs 2.65kg. At 5600K with a 45° reflector, it delivers 22,230 lux at 1m. With green and the 45° reflector, it delivers 10,200 lux at 1m. A single V-mount battery can power the fixture for portable setups.

Nebula C8 Color Engine

The Nebula C8 Light Engine uses eight color LEDs: Deep Red, Red, Amber, Lime, Green, Cyan, Blue, and Indigo. Its color-mixing algorithm provides a wider color temperature range, broader color gamut, and higher saturation for colored light. It also supports high color fidelity and improved skin tone reproduction in white light for natural and vibrant skin tones.

The Evoke 150C supports 0.1% dimming increments and fully linear dimming. This keeps low-brightness output smooth and creates natural transitions during fade-ins and fade-outs.

Built for Demanding Setups

The fixture combines the lamp head, control unit, and power supply in one body. Connect one cable to an AC wall outlet or use a D-Tap connection with a V-mount battery. Its magnesium alloy construction and optimized internal structure keep the fixture compact and lightweight. The full fixture carries an IP66 rating for protection against dust, sand, heavy rain, and harsh conditions.

The FE mount features electronic contacts and works with the FM mount accessory ecosystem. The NANLUX PosiTight system adds dual safety at the FE mount. Optional motorized accessories include a motorized yoke and FL-12E motorized Fresnel lens. The included AS-BP-QRS 5/8″ Baby Pin with Quick Release Plate supports fixed mounting through the fixture’s side quick-release base. Three anti-twist 1/4″-20 threads on the sides and top provide additional mounting points.

Flexible Power and Connections

The integrated AC/DC input accepts AC 100-240V or DC 14.4-28V without an additional adapter. The USB-C port supports PD3.0 input and above at 12-28V with a minimum of 60W. A compatible PD adapter, power bank, and USB-C cable are required. The extension port supports control devices, signal routing, communication with motorized accessories, and connectivity with the Evoke series control system.

Control the Evoke 150C from its 2.0-inch display, two adjustment knobs, and three mode buttons. The optional WC-EX wired controller uses an 8-meter cable and carries an IP66 rating. Wireless control is available through Bluetooth with NANLINK App 2.0. The fixture also supports DMX/RDM with the optional AS-EXT-DMX adapter, LumenRadio CRMX, and Art-Net/sACN through the optional AS-EXT-LAN adapter. The optional WS-RC-C2 remote provides wireless adjustments. NFC lets an NFC-enabled phone or tablet running NANLINK App 2.0 pair quickly and perform batch DMX setup for multiple lights, even while they are powered off.

Quiet Cooling and Transport

Five built-in fan modes manage cooling. In Smart mode, average noise measures only 24 dB(A). The fixture maintains quiet and stable output during extended full-power operation without interfering with on-set audio recording.

The Evoke 150C comes with a rigid-frame carrying bag with a padded interior for transportation and fixture protection. As part of the Evoke lineup, it joins daylight, bi-color, and color fixtures with power ratings up to 5000W. FE, BE, and NL mounts form the accessory ecosystem, while shared operation logic helps users work across different Evoke fixtures.

• Nebula C8 eight-color LED light engine
• 150W compact all-in-one fixture
• 22,230 lux at 1m at 5600K with 45° reflector
• 0.1% precise, fully linear dimming
• IP66 metal construction with magnesium alloy body
• AC 100-240V, DC 14.4-28V, USB-C PD3.0, and V-mount battery power
• DMX/RDM, CRMX, Art-Net/sACN, Bluetooth, NFC, and remote control options
• Five fan modes with 24 dB(A) average noise in Smart mode
