SmallHD INDIE 7 Touchscreen On-Camera Monitor
SmallHD INDIE 7 Touchscreen On-Camera Monitor
SmallHD INDIE 7 Touchscreen On-Camera Monitor
SmallHD INDIE 7 Touchscreen On-Camera Monitor

SmallHD INDIE 7 Touchscreen On-Camera Monitor

0 out of 5
( There are no reviews yet. )

5.350,00 AED ex. VAT
5.617,50 AED inc. VAT

  • 7-inch touchscreen monitor with customizable PageOS software.
  • 1000-nit brightness for outdoor and daylight viewing.
  • Includes focus and exposure assist monitoring tools.
  • Features dual 3G-SDI inputs and HDMI connectivity.
  • Compatible with Bolt RX Monitor Module and RED camera control upgrade.
SKU: MON-INDIE-7 Categories: , , Tag: Brand: SmallHD
International Orders: Shipping cost depends on your country and order weight. Please contact us to complete your order.

This Product For Pre Order Only, Delivery Time 3-4 Weeks

Related Products

Description

Indie 7 7-Inch Camera Monitor

The SmallHD Indie 7 is a vivid and lightweight entry model into SmallHD’s professional 7-inch touchscreen monitor series. Housed in a rugged and thin aluminum chassis, it is designed for heavy production use while remaining easy to handle on set. With 1000 nits of brightness and a hyper-responsive touchscreen, the Indie 7 gives you a reliable and personalized viewing experience in any environment or time of day.

PageOS and Imaging Tools

The Indie 7 runs on SmallHD’s user-customizable PageOS software, putting a full suite of internal imaging assistance tools at your fingertips. Focus Assist, Exposure Assist, and more help you monitor your production accurately and efficiently. The intuitive touchscreen interface makes navigating and adjusting settings fast and natural during any shoot.

Connectivity and Power Options

The Indie 7 features two 3G SDI inputs, with the second input also doubling as a loop out. An HDMI input and a 2mm barrel connector port add further connectivity flexibility. For power, a Sony L-Series dual battery bracket is built in, and the option to add a Gold Mount or V-Mount battery plate attachment gives you additional power versatility on set.

Optional Bolt RX Monitor Module

The Indie 7 is compatible with the optional Bolt RX Monitor Module, which upgrades your handheld monitoring workflow with cable-free 4K wireless video from any Bolt 4K series transmitter at distances of up to 750ft / 228m. As a result, you can monitor wirelessly with the same display quality and reliability you expect from a wired setup.

Camera Control for RED DSMC2 and KOMODO

SmallHD’s proprietary software enables camera control for RED DSMC2 and KOMODO cameras directly from the touchscreen. You can access and adjust Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more — transforming the Indie 7 into the central command hub of your camera system.

Key Features

  • 7-inch hyper-responsive touchscreen monitor in a lightweight aluminum chassis
  • 1000 nits brightness for direct sunlight and any environment viewing
  • Powered by user-customizable PageOS software
  • Focus Assist, Exposure Assist, and internal imaging tools
  • Two 3G SDI inputs — second input doubles as loop out
  • HDMI input and 2mm barrel connector port
  • Sony L-Series dual battery bracket included
  • Optional Gold Mount or V-Mount battery plate attachment
  • Compatible with Bolt RX Monitor Module for cable-free 4K wireless video
  • Wireless range up to 750ft / 228m with any Bolt 4K series transmitter
  • Camera control for RED DSMC2 and KOMODO via SmallHD proprietary software
Features Physical & Environmental
Construction Anodized Aluminum unibody
Dimensions (H x W x L/D) 4.67 x 1.32 x 7.09 in
Item Weight 18.9 oz
Package Weight 26 oz
Mount Points 4x ¼-20 Mount Points (Left, Right, Bottom, and Back)
Operating Temperature 32°F – 105°F
Compliance FCC, IC, CE, UKCA, RCM, BIS, ROHS
Features Display
Panel Type IPS LCD with touch
Diagonal Size 7.02″
Resolution 1920×1200
Aspect Ratio 16:9
Pixel Density 323 PPI
Active Area 5.95 x 3.72 in
Max Brightness 1000 Nits
Contrast Ratio 1000:1
Color Depth 10-bit Processing (8-bit panel)
Color Gamut DCI-P3 Color / 100% rec709
Viewing Angle 160°
Backlight Type LED (Adjustable: Yes)
Refresh Rate Synchronizes with input from 48Hz to 60Hz
Screen Protection Clear or Matte
Features Connectivity & Signal
SDI Connectors 1x BNC 3G input and 1x BNC 3G selectable input/output
3G-SDI Signal Types Input/Output: YCC 4:2:2 @ 10-bits:
1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
HD-SDI Signal Types Input/Output: YCC 4:2:2 @ 10-bits:
1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
SD-SDI Signal Types Input/Output: YCC 4:2:2 @ 10-bits:
480i59.94, 576i50
HDMI Connectors 1 input and 1 output: HDMI Type-D Receptacles (full size)
HDMI Input Types YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4:
3840×2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
HDMI Output Types YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4:
2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200
USB Connector 1x USB 2.0 Micro-B receptacle
Audio Configuration Input: HDMI & SDI (Monitor through Front Bezel Speakers or Headphone Jack; up to 8-channel metering)

Output: 1x 3.5mm 3-pin Stereo Headphone Jack; Incoming Audio Stream is sent downstream via HDMI or SDI connection
Features Power & Battery
Power Input Plug Barrel Connector (2.0mm ID, 5.5mm OD, center pin positive)
Voltage Range DC In: 10V minimum to 34V maximum
Battery Terminals: 6.0V minimum to 16.8V maximum
Power Consumption 17.3 watts (Tested at 2160p30, 100% brightness, tools enabled)
Current draw: 2.4A @ 7.2V battery, 1.4A @ 12V barrel, 0.7A @ 24V barrel
Included Battery Plate L-Series standard (V Mount or Gold Mount optional accessories)
Compatible Battery Types L-Series, V Mount, Gold Mount (Li-ion Chemistry)
Battery Charging Monitor does not support the charging of batteries
Recommended Power Supply DC 12~15V at ~2.5 amp or greater
Overload Protection DC input: Reverse polarity
Features Software & Monitoring Tools
Pixel Zoom 1.1-2.0x & 2.0-8.0x via swipe up/down; infinitely adjustable via pinch & zoom
Cross Conversion Yes: HDMI → SDI & SDI → HDMI
LUT Management Loadable as Looks on Pages or as Systemwide Color Calibration via settings menu. Import via SD Card or USB Storage Device. Downstream LUT available on SDI or HDMI Out (Applied on Output Preview Page).
Exposure Tools False Color (Rainbow, Arri Style, Custom with up to 10 nodes), Zebra (Dual – User Configurable)
Analysis Waveforms Waveform (Luma & RGB Style, fully customizable with Region of Interest Highlighting), Vectorscope, RGB Parade (Fully User Customizable), Histogram (Luma & RGB Style)
Focus Tools Focus Assist (User Adjustable Color Style and Intensity), Peaking (User Adjustable Intensity)
Framing & Scaling Frame Guides (Preset Aspect Ratios & Customizable), Anamorphic De-Squeeze (0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x), DSLR Scale (Canon 5DMkii & Canon 7D), Custom Scale (Underscan Only)
Image Control & Capture Image Capture, Image Rotate (Automatic/Manual), Image Flip (Automatic/Manual), Overlay (with Opacity Slider and Blink Setting)
Audio Monitoring Audio Meters (HDMI & SDI up to 8 channel)
  • Indie 7
  • Sony L Series Battery Bracket
  • SmallHD Cleaning Cloth
