SWIT 4 Channel V-Mount Simultaneous Fast Charger

0 out of 5
( There are no reviews yet. )

1.850,00 AED ex. VAT
1.942,50 AED inc. VAT

  • 4-Channel Fast Charging: Charges four V-Mount batteries in 2–3 hours.
  • Dual XLR Outputs: Two 15V, 6A, 90W outputs for devices (optional cable needed).
  • LED Indicators: Red, yellow, green lights show charging status.
  • Safety Features: Battery protection with optimized charging curve.
  • Portable Build: Compact, lightweight, and AC input compatible.

Availability: 3 in stock SKU: PC-P430S Categories: , , , Tag:

Related Products

Description

4-ch Simultaneous Quick Charger

SWIT PC-P430S 4-ch Simultaneous Quick Charger For V-mount batteries, PC-P430S can charge 4pcs V-mount camera batteries simultaneously. The charging output is DC16.8V, 3A each channel.

The PC-P430S has LED charging indicators on the front panel, indicates the real time capacity of each channel by different colors:

  • Display Red: Battery is charging, capacity below 80%;
  • Display Yellow: Battery is charging, capacity above 80%;
  • Display Green: Charging finished.

PC-P430S has 2x 4-pin XLR female connector on the front panel. Connected with SWIT S-7102 XLR female to male cable (optional purchase), the PC-P430S can be used as AC-DC adaptor of 2-ch DC 15V, 6A, 90W simultaneous output.
*Please note the AC-DC adapting output will not work when battery is charging.

The SWIT 4 Channel V-Mount Simultaneous Fast Charger (SKU: PC-P430S) is a robust and efficient charger tailored for professional film and video production. It simultaneously charges up to four V-Mount lithium-ion batteries at 16.8V, 3A per channel, enabling fast charging for high-capacity batteries (e.g., approximately 2 hours for 160Wh, 3 hours for 270Wh batteries). The charger features two 4-pin XLR female connectors, allowing it to function as an AC-DC adapter with 2-channel DC 15V, 6A, 90W simultaneous output for powering cameras, monitors, lights, or other accessories when not charging batteries. LED indicators provide real-time charging status: red (charging, below 80% capacity), yellow (charging, above 80%), and green (charging complete). With a compact vertical design, weighing 3.27kg and measuring 285 x 144 x 173mm, it includes a top handle for portability and supports global 100–240V AC input.

Key Features

The SWIT PC-P430S charger is engineered with professional-grade features:

  • Simultaneous 4-Channel Charging: Charges four V-Mount batteries at 16.8V, 3A per channel, supporting fast charging for lithium-ion batteries, with typical charging times of 2–3 hours for 160–270Wh batteries.
  • Dual XLR DC Output: Equipped with two 4-pin XLR female connectors delivering 15V, 6A, 90W each, usable as an AC-DC adapter for cameras, lights, or monitors when not charging (requires optional SWIT S-7102 XLR cable).
  • LED Charging Indicators: Displays red (charging, <80%), yellow (charging, >80%), and green (complete) for each channel, providing clear visual feedback on charging progress.
  • Safety Protections: Features overcurrent, overcharge, and high-temperature protection, with a two-period charging curve (constant-current, constant-voltage) to prevent battery damage and ensure longevity.
  • Portable Design: Weighs 3.27kg, measures 285 x 144 x 173mm, and supports 100–240V, 50/60Hz AC input, with a top handle and maximum power consumption of 276W, certified with CE, UN, GVV, UL, and FCC/EMV standards.
Power Max276W
Input AC100V-240V 50/60Hz
Charging Output DC 16.8V, 3A×4
Adapting Output DC 15V, 6A×2
Dimensions 285×144×173mm
Net weight Net 3.27kg; With package 3.8kg
